RBSE25N

20MM WIDE, WELD ON TO BASE
HYDRAULIC CYLINDER COMPONENT

RBSE25CH

28MM WIDE, WELD ON TO ROD
HYDRAULIC CYLINDER COMPONENT

RBSE25NH

28MM WIDE, WELD ON TO BASE
HYDRAULIC CYLINDER COMPONENT

RBSE25C

20MM WIDE, WELD ON TO ROD
HYDRAULIC CYLINDER COMPONENT

RBSE25U

20MM WIDE, M16x1.5 THREAD ON TO ROD
HYDRAULIC CYLINDER COMPONENT

RBMB25-28-20-X

RBMB25-28-30-X

R5926.03.00

R5426.02.25

R5427.01.75

R5427.02.37

RBNN2723

R5828.03.00

R5928.03.00

R5428.02.00

R5428.03.00

C253/3

R5429.04.00

ACTUAL DIMS ARE 3.93'' BORE,1.97''
ROD, 28.54'' CC,19.7'' STROKE & 1.1
PIN HOLES

R6028.03.75

28" CLOSED CENTRE
1420MM STROKE
3 3/4", 3", 2 3/8" BORES
1 1/4" ROD, 25.8MM PIN HOLES
105MM O/D

RT3/914/110

914MM CLOSED CENTRE
2032MM STROKE
110MM, 90MM, 70MM BORES
50MM ROD, 32.5MM PIN HOLES
120MM O/D

RT3/1067/100

1067MM CLOSED CENTRE
2479MM STROKE
100MM, 80MM, 60MM BORES
45MM ROD, 25.5MM PIN HOLES
110MM O/D. NITRIDE STAGES

R6039.03.75

39" CLOSED CENTRE
2191MM STROKE
3 3/4", 3", 2 3/8" BORES
1 1/4" ROD, 25.8MM PIN HOLES
105MM O/D

RT3/924/100

924MM CLOSED CENTRE
1993MM STROKE
95.2MM, 76.2MM, 60.3MM BORES
44.45MM ROD, 25.8MM PIN HOLES
105MM O/D

RT3/1092/110

1092MM CLOSED CENTRE
2449MM STROKE
110MM, 90MM, 70MM BORES
50MM ROD, 32.5MM PIN HOLES
120MM O/D

RT3/1016/110

1016MM CLOSED CENTRE
2323MM STROKE
110MM, 90MM, 70MM BORES
50MM ROD, 32.5MM PIN HOLES
120MM O/D
